Product Details:
Payment & Shipping Terms:
|
| Machine Name: | 1.5-2.5T/H Animal Feed Machine | Machine Capacity: | 1.5-2.5t/h |
|---|---|---|---|
| Pellet Size: | 1.5-12mm | Voltage: | 220v,380v,or Customized |
| Diameter Of Ring Die: | Φ250mm | Diameter Of Roller: | Φ110mm |
| Motor: | Siemens Motor | Application: | Poultry Animal Feed, Farm, Or Pellet Line |
| High Light: | pellet making machine,feed pellet making machine,animal pellet machine |
||
1.5-2.5T/H Animal Feed Machine Poultry Feed Pellet Making Machine
Brief Introduction of Animal Feed Machine Poultry Feed Pellet Making Machine
1. Belt Transmission type szlh250 feed pellet machine
2. Die roller fixed with stainless steel knife pelletizing device
3. This pellet mill die roller is suitable for making high quality livestock and poultry, pig,
dog, chicken feeds and other materials in feed pelleting.
Advantages of Animal Feed Machine Poultry Feed Pellet Making Machine
1.SIEMENS Motor
2.NSK Bearing
3.Frequency conversion feeding motor
3.Plate is 2mm thicker than the common, durable to use
Features of SZLH250 Animal Feed Machine
1) High efficiency
Stable and classical gear driving,non-slipping,can really ensure the production output. Low noise,optimized ring die,maximum output.
2) Hygiene and safety
CE certified standard design and available stainless conditioner for feed,human and machine safety.
3) Flexible production
Wide product rangeΦ1.5mm-Φ12mm pellets,conditioner with molasses and steam adding function.
4) User-friendly operation
Hydraulic system for ring die change and roller adjustment(optional),quick ad precise operation；auto-lubrication system(optional)and die & roller lifting device,save labor；on-site touch screen control.
Technical Parameters of SZLH 250 Animal Feed Machine
| Items | Technical Parameter (SZLH250) |
| Production Capacity | 1.5-2.5t/h |
| Power of Main Motor | 380V 50Hz 3 Phase 22 KW (Can be customized) |
| Power of Feeding Screw Motor | 0.75 KW |
| Power of Conditioner | 1.5 KW |
| Inner Diameter of ring die | Φ250mm |
| Efficient width of ring die | 80mm |
| Speed of ring die | 300rpm |
| Speed of feeding screw | 12-120rpm |
| Speed of Conditioner | 350rpm |
| Pellet specification | φ2,φ3,φ4,φ4.5,φ5,φ6,φ8,φ10mm |
| Amount of roller | 2 |
| Diameter of Roller | Φ110mm |
| Pellet Ratio of Briquetting | ≥ 95% |
| Percentage of powdered Pellet | ≤12% |
| Stability of pellet in the water | ≥20min |
| Noise | ≤85dB(A) |
| Working temperature of ring die | ≤85℃ |
| Working pressure of steam | 0.3Mpa |
| Steam consumption | 50kg/H |
| Temperature of steam | 130-150℃ |
| Packing Size (length×width×height) | 2450*1550*2200mm |
| Machine Size | 2250*1430*2040mm |
| Net/Gross Weight | 1150KG/1445kg |
