Product Details:
Payment & Shipping Terms:
|
| Type: | Chicken Feed Pellet Making Machine Plant | Yield: | 5T/H |
|---|---|---|---|
| Final Pellet: | 2-10mm | Main Machine Power: | 300kw |
| Main Machine: | Crusher,mixer,pellet,cooler,screener Machine | Application: | Cow Sheep Livestock Feed |
| High Light: | 300KW Feed Pellet Making Machine,2mm Feed Pellet Making Machine,5T/H Feed Pellet Making Machine |
||
SZLH350 300KW Chicken Feed Pellet Making Machine Plant
The animal feed pellet making machine plant is designed for small, medium and large feed mills, poultry farms, animal farms and aquafarms. According to different requirements of the cattle feed processing plant output, the capacity of this animal feed processing plant ranges from 1TH to 30 TH.
Complete feed pellet making plant Including:
raw materials receiving and cleaning process,
crushing process,
mixing process,
pellet making process,
pellet cooling process,
sifting process
packaging process.
Technical Parameters of Chicken feed pellet making plant
| Item | Name | Type | Qty | Power (KW) |
| Part 1. Raw material receiving& crushing system | ||||
| 1 | Grass crusher | FSP500B-22 | 1 | 22 |
| 1-103 | Impulse Filter | TBGM20 | 1 | |
| 1-105 | Bucket Elevator | TDTG36/23 | 1 | 4 |
| 1-106 | Cylinder Filtering Sieve | TCQY63 | 1 | 0.75 |
| 1-107 | Additive Blender | TCXT20 | 1 | |
| 1-110 | Impeller speed regulating Feeder | SWLY60 | 1 | 1.1 |
| 1-111 | Crusher | SFSP66*60 | 1 | 55 |
| 1-114 | Impulse Filter | TBLMa24 | 1 | |
| 1-116 | Wind-shielding Screw conveyor | TLSB20 | 1 | 2.2 |
| Part 2. Mixing System | ||||
| 2-202 | Bucket Elevator | TDTG36/23 | 1 | 4 |
| 2-203 | Powder Screener | SCQZ60 | 1 | 5.5 |
| 2-207 | Feeder for additive | 1 | ||
| 2-208 | Mixer | SLHS1.0 | 1 | 11 |
| 2-210 | Scraper Conveyor | TGSU20 | 1 | 3 |
| Part 3. pelleting system | ||||
| 3-308 | Pellet Mill | SZLH350 | 1 | 57.95 |
| 3-310 | Cooler | SKLN3 | 1 | 1.5 |
| Part 4. Packing system | ||||
| 4-401 | Bucket elevator | TDTG36/18 | 1 | 3 |
| 4-402 | Rotary Screener | SFJH80*2d | 1 | 2.2 |
| 4-409 | Auto Packing Scale | 10-50KG | 1 | 1.5 |
| 4-410 | Stitch conveyor | 1 | 1.5 | |
| Part 5. Auxiliary Equipment System | ||||
| 5-506 | Steam Supplying System | 1 | ||
| 5-507 | Oil adding System | 1 | 2.2 | |
| 5-508 | Oil Adding Tube | 1 | ||
| 5-509 | Calabash Crane | 1 | 3 | |
