Product Name:	Poultry Feed Pellet Making Plant	Capacity:	1-2.5t/h
Motor:	Siemens	Pellet Mill Bearing:	NSK Or SKF
Application:	Produce Feed For Poultry,chicken,duck,rabbits,pig	Weight:	3200kg
Power:	95KW	Voltage:	380V/50Hz
Installation:	Offer Manual Book And Engineer's Guidance	Main Machines:	Grinder,mixer,Pellet Mill,pellet Crusher
High Light:	animal feed production plant , poultry feed mill equipment

No.	Product	type		Power(KW)
1.Raw materials receiving and crushing and mixing system
101	Screw Conveyor	TSLL16		2.2
102	Hammer Crusher	SFPZ56*20		15.00
103	Ribbon Mixer	SHW1.0		7.5
2.Pelleting system
201	Bucket Elevator	TDTG36/18	2.2
204	Pellet Machine(include control box)	SZLH25	11*2+2.2+0.75
3.Cooling system
303	Airlock	GFY250	0.75
304	Counter Flow Cooler	SKLN11×11	0.75
305	Air Blower	4-72-4A	5.50
308	Pellet crusher	SSLG15*80	5.5
309	Manual Three-way	SD20*20
4.Auxiliary System
402	Rotary Screener	SFJH80*2d	1.5
5.Auxiliary System
601	Boiler

Hammer Crusher Adopts regrinding crushing technology, widen the screen in 360°,the materials can be crushed averagely. Ribbon Mixer Coefficient of variation is less than 5%, the mixing time is 5 minutes, then the materials can be discharged form one side. There is no dead corner when mixing, and this machine is easy to maintenance.
SZLH250 Pellet Machine(include control box) Good quality ting die, stainless steel conditioner, reliable working, adopts double motors driving, over-loading protection.
Counter Flow Cooler Adopts counter-flow cooling technology, the pellets can be cooled averagely and no crack. The cooling time and volume can be adjusted, and there are no residues by discharging.
Crumbler for animal pellet production plant Different poultry, livestock or aquatic feed pellets are with different sizes. Some big ones should be crushed into small ones. Double-roll feed pellet crumbler is suitable for crushing poultry feed, such as chicken feed, duck feed and goose feed etc.
Rotary Screener for animal feed plant The crushed feed pellets are with different sizes, and there may be some powder. The rotary grading sieve can be used to screen and grade the feed pellets. After processing, you can get the qualified feed pellets without fine powder.
Boiler for animal feed production plant Provide steam for SZLH250 feed pellet machine
Feed Pellet Packing Process The feed pellets should be packed for transporting, storing or selling. Automatic weighing and packing machine can weigh and pack the pellets automatically with high accuracy.

The raw material and finished pellet The feed pellets are usually made of corn, brown rice, paddy, alfalfa ,elephant grass, Ryegrass,sorghum and soybean meal etc

	Factory Address:southeast corner of the intersection of Heshuo Avenue and Shantao Road,Wuzhi County industrial zone

	Sales office:southeast corner of the intersection of Heshuo Avenue and Shantao Road,Wuzhi County industrial zone

	+86-0371-55011568

	toppelletmachine@gmail.com

380V 50Hz Pellet Making Equipment , SZLH 250 1-2TPH Animal Feed Processing Plant

380V 50Hz Pellet Making Equipment , SZLH 250 1-2TPH Animal Feed Processing Plant

animal feed production plant

poultry feed mill equipment

1. Introduction of poultry feed pellet making plant

2.Technical Parameters of main equipments for poultry feed pellet production line

3.Main Equipments For poultry feed pellet making plant

Equipment Related to poultry feed pellet production line machine

Feed Grinder →Feed Mixer → Feed Pellet Mill → Counter flow Cooler → Feed Pellets Crumbler → Feed Pellets Grading Sieve → Automatic Weighing and Packing Machin
