Product Details:
Place of Origin: Henan,China
Brand Name: Strongwin
Certification: CE,ISO
Model Number: 15-20t/h
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: container
Delivery Time: 30 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10sets/month
Detailed Product Description
Characteristics: Running Efficient, Stable Motor: Siemens Motor
Bearing: NSK Or SKF Function: Produce Feed Pellets For Chicken Duck Rabbits Cattle Cow
Main Equipments: Hammer Mill ,mixer, Pellet Machine, Cooler,sieve Pellets Diameter: 2,3,4,5,6,7,8 Mm
High Light:

poultry feed production line


animal feed plant machinery

20 TPH Double Szlh420 Animal Feed Productiuon Line To Build Feed Factory
This complete Livestock Feed Production Line is suitable for producing all kinds of feed pellets for various animals such as chicken, pig, cow, cattle, goat, rabbit and fish, etc.
Just use different size of ring die mould to produce different animal feed pellet according to the requirement of different animal and poultry.
The replacement of the ring die mould is very easy.
 20 TPH Animal Feed Production Line Double Szlh420 For Feed Factory High Efficiency 0

1. Cleaning and Crushing Part


Function: remove the impurities from the raw material to ensure the quality of the final feed pellets and avoid the damage to the machine.


Drum-type Precleaner:Remove the impurities mixed in the raw material.

Permenant magnetic sleeve:Remove the iron, steel, nails, etc.

Hammer Mil: Crush the material into small particles suitable for pellet making.


2. Batching & Mixing Part

Function: batch different type raw material into mixer for mixing evennessly according to different animal formula requirements.


Multi-outlet Rotary Distributor:With multi-outlet for distributing different crushed material to pointed silo waiting fo mixing.


Batching Scale:Controlled by computer, 1000kg/batch, when material reaches this capacity, it will be automatically dropped to the hopper under it.


Mixer:Mix different raw material discharged by the batching scale together evennessly.


3. Pelleting&Cooling&Crumbling Part


Function: press the mixed well material into feed pellets, after the cooling of pellets, if needed, the pellets will be crumbed into small pellets


Feed Pellet Machine:Euipped with conditioner, this pellet machine will steam and soft the material first to kill the bacteria and improve the qualitiy and capacity of final feed pellets.

Cooling Machine:For cooling the final pellets to normal room temperature.


Pellet Crumbling Machine:Crumbling the final feed pellets to small pieces(small animal needs).

 20 TPH Animal Feed Production Line Double Szlh420 For Feed Factory High Efficiency 1
Technical Parameters


15-20 T/H Animal Feed Pellet Production Line
No. Product name Model Qty Power(kw)
1. material receiving section
104 Bucket elevator TDTG48/28 2 5.5
105 granule material clean sieve SCY80 1 0.75
106 permanent magnetic TXCT25 1
111 rotary distributor TFPX.8 1 0.55
2. material grinding section
205 Impeller feeder SYLW3 1 1.50
206 Tear-circle hammer mill SDH-ZW50C 1 132
209 seal screw conveyor SWLL25 2 6.00
210 Impeller feeder SYLW3 1 1.5
211 Tear-circle hammer mill SDH-ZW80B 1 90
212 Fan 4-72-N04.5A 1 11
213 pulse dust collector TBLFa.42 1
3. batching and mixing section
311 small material feeding   1
312 pneumatic valve TZMQ32*32 1
313 316

Double shaft high efficient mixer
Double shaft high efficient mixer

SSHJ.2 SSHJ.4 1 1 18.5 30
317 Leveler RP 1
318 Vibration hammer   1
319 scrapper conveyor TGSU25 1 3.00
322 powder material clean sieve SCQZ80 1 11
4. pelleting section
404 vibration pneumatic hammer   4
407 Pellet machine SZLH420 2 220.00
409 counter-current cooler SKLN6 2 3.0
410 crusher SSLG20×170 2 30
412 Fan 4-72No6C 2 30
413 discharger SKL1000 2
415 Bucket elevator TDTG40.28 2 8
416 classic sieve SFJH125 2 6
5. packing section
507 automatic packing scale SDBY-P 2
508 seal conveyor machine TFKB40 2 6
510 pulse dust collector TBLFa.24 1
511 seal machinery   1 0.75
512 Fan 4-72-N04.5A 1 7.50
513 pulse dust collector TBLFa.30 1
6.auxiliary system
601 Air compressor   1 22.00
602 storage air tank   1
603 Dryer   1
604 liquid adding machine SYTV63 1 3.00
606 Steam boiler system 2T 1

animal feed production line
