Product Details:
Payment & Shipping Terms:
|
| Name: | 1.5-2.5 T/H Chicken Bird Duck Pig Poultry Feed Mill Plant | Type: | SZLH250 Ring Die |
|---|---|---|---|
| Capacity: | 1.5-2.5T/H | Power: | 70kw |
| Pellet Size: | 2-15mm | Main Machine: | Crusher,mixer,pellet,cooler,crumbler,screener,packing Machine |
| Application: | Feed Factory, Feed Mill | ||
| High Light: | Chicken Bird Poultry Pellet Feed Plant,1.5T/H Poultry Pellet Feed Plant,Poultry Pellet Feed Plant 70kw |
||
1.5-2.5 T/H Chicken Bird Duck Pig Poultry Feed Mill Plant
This type poultry feed mill plant advantages
1, Ring die pellet model can improve the production capacity.
2, Adopts high accuracy gearbox for high efficiency.
3, Stainless steel conditioner to ensure the high quality of pellet feed.
4, Siemens motor, SKF bearing
5, High output, low noise, compact structure, convenient operation and maintenance.
Process of poultry feed mill plant
feed grinder, feed mixer, feed pellet, feed cooler, feed screener, feed crumbler, packing machine etc.
Widely apply to kinds of poultry animals.
Technical Parameters of poultry feed mill plant
| No. | Product | Type | Power(KW) |
| 1.Raw materials receiving and crushing and mixing system | |||
| 101 | Screw Conveyor | TSLL16 | 2.2 |
| 102 | Hammer Crusher | SFPZ56*20 | 15 |
| 103 | Ribbon Mixer | SHW1.0 | 7.5 |
| 2.Pelleting system | |||
| 201 | Bucket Elevator | TDTG36/18 | 2.2 |
| 204 | Pellet Machine(include control box) | SZLH250 | 11*2+2.2+0.75 |
| 3.Cooling system | |||
| 303 | Airlock | GFY250 | 0.75 |
| 304 | Counter Flow Cooler | SKLN11×11 | 0.75 |
| 305 | Air Blower | 4-72-4A | 5.5 |
| 308 | Pellet crusher | SSLG15*80 | 5.5 |
| 309 | Manual Three-way | SD20*20 | |
| 4.Auxiliary System | |||
| 402 | Rotary Screener | SFJH80*2d | 1.5 |
| 5.Auxiliary System | |||
| 501 | Boiler | ||
