Pelletizing SZLH350 10mm 5T/H Animal Feed Mill Plant

Pelletizing SZLH350 10mm 5T/H Animal Feed Mill Plant
Pelletizing SZLH350 10mm 5T/H Animal Feed Mill Plant

Large Image :  Pelletizing SZLH350 10mm 5T/H Animal Feed Mill Plant

Product Details:
Place of Origin: China
Brand Name: Strongwin
Certification: CE,ISO,SGS
Model Number: 5t/h feed mill plant
Payment & Shipping Terms:
Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: Wooden Case or In Container
Delivery Time: 15-30 working days after deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per year
Detailed Product Description
Capacity: 5T/H Final Pellet: 2-10mm
Main Machine Power: 300kw Name: Animal Feed Mill Plant Business Plan
Main Machine: Crusher,mixer,pellet,cooler,screener Machine Motor: Siemens
High Light:



5T/H Animal Feed Mill Plant


10mm Animal Feed Mill Plant

Pelletizing SZLH350 10mm 5T/H Animal Feed Mill Plant


Turnkey projects for Customers( Engineers design and Installation, Steel structure workshop and silos)


Animal feed mill plant processing craft( this is brief craft)

Raw Material → Feed Grinding → Feed Mixing → Feed Pelletizing → Pellet Cooling → Pellet Crushing → Screening & Grading → Pellet Packing


Main machine introduction of animal feed mill plant


Water-drop hammer crusher machine

Adopting international advanced technique, crush room is designed as water drop. With special twice crush design, crush efficiency is greatly improved. With full open operating door, elasticity sieve pressing mechanism, easy to maintain and replace sieve.


Double shaft paddle mixer

The improvement of open door shaft and link mechanism ensure that the angle of openning door is larger than 90-(the materials can’t fall on the door), close door which is deadlocked.

Advanced adding and spraying system could be added many kinds of liquid and solid at the same time, Precision spraying and convenient control.


Ring die feed pellet machine

Ring die pellet machine main engine drives, high precision gear, ring die in quick detaching encircling hoop type, output higher 20% than belt drive

Equipped with steam automatic regulatory system to keep refining temperature constant

Larger type strengthen feeding conditioner in entire stainless steel with frequency speed control, ensure the high quality of pellet feed.


Counter-flow cooler machine

Eight corner structure without residue

High temperature resistance of Inspection window

Direct type reducer, Motor with emergency stop


Screener machine

Low breakdown, less maintenance, simple operation, the gearbox adopts non-gear transmission way, dispense with oil lubrication, avoid oil pollution with oil leakage

It changes the tail sliding support into elastic support, avoid deposited material avoid cross contamination


Pelletizing SZLH350 10mm 5T/H Animal Feed Mill Plant 0


Technical Parameters of animal feed mill plant


Item Name Type Qty Power (KW)
Part 1. Raw material receiving& crushing system
1 Grass crusher FSP500B-22 1 22
1-103 Impulse Filter TBGM20 1
1-105 Bucket Elevator TDTG36/23 1 4
1-106 Cylinder Filtering Sieve TCQY63 1 0.75
1-107 Additive Blender TCXT20 1
1-110 Impeller speed regulating Feeder SWLY60 1 1.1
1-111 Crusher SFSP66*60 1 55
1-114 Impulse Filter TBLMa24 1
1-116 Wind-shielding Screw conveyor TLSB20 1 2.2
Part 2. Mixing System
2-202 Bucket Elevator TDTG36/23 1 4
2-203 Powder Screener SCQZ60 1 5.5
2-207 Feeder for additive   1
2-208 Mixer SLHS1.0 1 11
2-210 Scraper Conveyor TGSU20 1 3
Part 3. pelleting system
3-308 Pellet Mill SZLH350 1 57.95
3-310 Cooler SKLN3 1 1.5
Part 4. Packing system
4-401 Bucket elevator TDTG36/18 1 3
4-402 Rotary Screener SFJH80*2d 1 2.2
4-409 Auto Packing Scale 10-50KG 1 1.5
4-410 Stitch conveyor   1 1.5
Part 5. Auxiliary Equipment System
5-506 Steam Supplying System   1
5-507 Oil adding System   1 2.2
5-508 Oil Adding Tube   1
5-509 Calabash Crane   1 3


Pelletizing SZLH350 10mm 5T/H Animal Feed Mill Plant 1
