|Name:||Wet Type 1 T/H Fish Food Processing Machine Paking To Ukraine||Capacity:||1-1.2t/h|
|Crusher Machine Capacity:||3t/h||Mixer Machine:||5.5t/h|
|Application:||Kinds Of Aqua Fish Food||Shipping:||By Sea|
1T/H Floating Fish Feed Plant,
Wet Type Fish Food Extruder Machine,
1TPH Fish Food Extruder Machine
Wet Type 1 T/H Fish Food Processing Machine Paking To Ukraine
Craft of fish food processing machine
Feed crusher→Feed mixer→wet type Fish feed extruder→Pellets dryer→Automatic weighing and packing machine
Material crushing—feed hammer mill
Raw material ingredients should be grinded to the required size by feed grinder.
SPSF feed Hammer mill is used for grinding raw materials by large and medium livestock and aqua feed mills;
Material mixing—feed mixer
Mixing the material thoroughly can ensure extruding efficiency and improve the feed quality. double-shaft efficient mixer can be applied to mixing powdery, granular, flaky and blocky materials. This mixers can be customized with atomizing spraying system which will add liquid like molasses and grease to material more evenly.
Extruding process—Wet type fish food processing machine
The wet type fish food extruder machine is with the conditioner and need to equipped the steam boiler. Capacity of wet type fish feed extruder is higher than dry type ones, so usually the wet type extruder machine is suitable for large feed pellet factory.
Pellets drying—feed pellet dryer
Our mesh belt dryer is a continuous convective belt dryer. Pellets formed through the extruder are stacked in layers on a wire mesh or perforated plate belt conveyor and conveyed continuously through drying chambers.
During this process, the drying air is passed repeatedly through the products layer until pellets have the optimum moisture content before leaving the dryer. While if you choose wet type fish feed machine, we recommend the gas type pellet dryer.
Pellet packing—electronic packing machine
To make the finished pellets easy to store, transport and catch the clients’ eyes, they should be packed properly. With our electronic weighing and packing machine, the finished pellets can be packed into bags, weighed, conveyed, and sealed automatically, which saves labor and time greatly and meet the requirements of large scale production. For this packing machine, automatic heat typing code, automatic bag sewing and automatic thread cutting can be optional functions.
Technical Parameters of fish food processing machine equipment
|Main Technical Parameters of Main equipments of DSP135-B fish feed extruding line machine|
|Main Machines||Power (kw)||Capacity (kg/h)||Dimensions(mm)||Weight (kg)|
|Mixer||11||500kg/batch, need 10-15 minutes per batch.||2400*1050*1700||580|
|DSP135-B||Main power75kw;Feeding motor power:1.1kw;Modified motor power:3kw;Cutting motor power:2.2kw||1000-1200||3750*1980*1800||2000|
|dryer||Mesh belt motor power:5.5kw;Feed motor power:0.75kw'Exhaust fan power:1.1kw;Circulating fan power:0.55kw;amount of steam required:0.2-0.3MPa||1000-2000||5850*1600*2400||2200|
|Drum-type Spray Machine||main power2.2kw;Oil pump power:0.55kw;Oil drum heating power:1.5kw||1000-2000||5000*800*1550||260|
|Counter current cooler||Fan power:4.0kw;Shakron discharger power:0.75kw;The discharge method is pneumatic discharge||1000||1800*1500*2400||980|
|Automatic weighing package||1.1||≤300bag/hour;Packing range: 1-50kg/bag||2400*800*2940||576|
|Steam boiler||0.4-0.8MPa||0.5-0.8t/h Steam volume|
